Parker Compax3 Fluid T40

Compax3 Accessories C3F_T40
432 192-121102 N04 June 2008
In this chapter you can read about:
ZBH plug set.....................................................................................................................432
Cable for path measurement systems..............................................................................432
Operator control module BDM..........................................................................................435
EAM06: Terminal block for inputs and outputs.................................................................436
Interface Cables ...............................................................................................................439
Options M1x .....................................................................................................................447
Profibus plug BUS08/01 ...................................................................................................451
CAN - plug BUS10/01 ......................................................................................................452
PIO: Inputs/Outputs..........................................................................................................453
11.1 ZBH plug set
The plug set which is available as accessory comprises:
 a shield connecting terminal for the large area shield connection of the sensor
and valve cable (X1, X2), as well as
 the mating plug connectors for the Compax3 plug connectors X1, X2, X3, and
 fixing material for the mounting of a supporting rail
Order Code connection set for Compax3 Fluid
/
for C3F00xD2 ZBH 02/04
ZBH
0 2 / 0 4
ZBH02/04: for Compax3 F00x D2
11.2 Cable for path measurement systems
In this chapter you can read about:
Encoder cable...................................................................................................................433
Feedback cable (Balluff)...................................................................................................434
Feedback cable EnDat2.1 ................................................................................................435
11. Compax3 Accessories
