11.9 PIO: Inputs/Outputs
Additional external digital and analog inputs and outputs can be integrated via
CANopen.
For this purpose we offer the Parker I/O system (PIO).
PIO offers the convenience of exceptionally simple installation. The individual
modules can be installed and removed without any tools.
Available modules:
Order Code decentralized input terminals
PIO 2DI 24VDC 3.0ms 2-channel digital input terminal
PIO 4 0 0
PIO 4DI 24VDC 3.0ms 4-channel digital input terminal
PIO 4 0 2
PIO 8DI 24VDC 3.0ms 8-channel digital input terminal
PIO 4 3 0
PIO 2AI DC ± 10V differential
input
2 channel analog input terminal (± 10V differential input)
PIO 4 5 6
PIO 4AI 0-10VDC S.E. 4 channel analog input terminal (0-10V signal voltage)
PIO 4 6 8
PIO 2AI 0 -20mA differential
input
2 channel analog input terminal (0 -20mA differential input)
PIO 4 8 0
Order Code decentralized output terminals
PIO 2DO 24VDC 0.5A 2 channel digital output terminal (output voltage 0.5A)
PIO 5 0 1
PIO 4DO 24VDC 0.5A 4 channel digital output terminal (output voltage 0.5A)
PIO 5 0 4
PIO 8DO 24VDC 0.5A 8 channel digital output terminal (output voltage 0.5A)
PIO 5 3 0
PIO 2AO 0-10VDC 2 channel analog output terminal (0-10V signal voltage)
PIO 5 5 0
PIO 2AO 0 -20mA 2 channel analog output terminal (0-20mA signal voltage)
PIO 5 5 2
PIO 2AO DC ± 10V 2 channel analog output terminal (± 10V signal voltage)
PIO 5 5 6
Order Code CANopen Fieldbus Coupler
CANopen Standard max. vectorial sum current for bus terminals 1650mA at 5V
PIO 3 3 7
CANopen ECO max. vectorial sum current for bus terminals 650mA at 5V
PIO 3 4 7
For additional information please refer to our catalog
http://www.parker.com/euro_emd/EME/Literatu
re_List/dokumentationen/PIO_catal
ogue%20eng.pdf.
