Parker EME
Setting up Compax3
192-121102 N04 June 2008 79
4.1.14. Encoder Simulation
You can make use of a permanently integrated encoder simulation feature to make
the actual position value available to additional servo drives or other automation
components.
The encoder simulation is not possible at the same time as the encoder input
resp. the step/direction input or the SSI interface.
The same interface is used here.
A direction reversal configured in the C3 ServoManager does not affect the
encoder simulation.
The direction of rotation of the encoder simulation can, however, be changed via
the feedback direction in the MotorManager.
Simulated Encoder Output Resolution
Unit: Increments per
500mm*
Range: 4 - 16384 Standard value: 1024
Any resolution can be set
Limit frequency: 620kHz i. e. for:
Increments per 500mm max. velocity
1024 30m/s
4096 7.5m/s
16384 1.8m/s
* or with a rotary feedback travel per feedback rotation
Caution!
