Compax3 - Objects C3F_T40
426 192-121102 N04 June 2008
Bus object No. Object name Object PNU CAN No. Format PD Valid
beginning
I20 I21 / I22
153.2 C3Plus.RemoteAnalogOutput_O1 PIO analog output 1
0x2083.2 I16 yes Immediat
ely
- X
153.3 C3Plus.RemoteAnalogOutput_O2 PIO analog output 2
0x2083.3 I16 yes Immediat
ely
- X
153.4 C3Plus.RemoteAnalogOutput_O3 PIO analog output 3
0x2083.4 I16 yes Immediat
ely
- X
150.1 C3Plus.RemoteDigInput_I0_15 Digital PIO inputs 0...15
0x2080.1 V2 yes Immediat
ely
- X
150.2 C3Plus.RemoteDigInput_I16_31 Digital PIO inputs 16...31
0x2080.2 V2 yes Immediat
ely
- X
150.3 C3Plus.RemoteDigInput_I32_47 Digital PIO inputs 32...47
0x2080.3 V2 yes Immediat
ely
- X
150.4 C3Plus.RemoteDigInput_I48_63 Digital PIO inputs 48...63
0x2080.4 V2 yes Immediat
ely
- X
151.1 C3Plus.RemoteDigOutput_O0_15 Digital PIO outputs 0...15
0x2081.1 V2 yes Immediat
ely
- X
151.2 C3Plus.RemoteDigOutput_O16_31 Digital PIO outputs 16...31
0x2081.2 V2 yes Immediat
ely
- X
151.3 C3Plus.RemoteDigOutput_O32_47 Digital PIO outputs 32...47
0x2081.3 V2 yes Immediat
ely
- X
151.4 C3Plus.RemoteDigOutput_O48_63 Digital PIO outputs 48...63
0x2081.4 V2 yes Immediat
ely
- X
2403.2 C3Plus.SignalFlowCharacteristic_Ch0_Curve_ID_
A
Which characteristic (ID) is used
I16 no VP - -
2403.1 C3Plus.SignalFlowCharacteristic_Ch0_Type Characteristic output 0
I16 no VP - -
2413.2 C3Plus.SignalFlowCharacteristic_Ch1_Curve_ID_
A
Which characteristic (ID) is used
I16 no VP - -
2413.1 C3Plus.SignalFlowCharacteristic_Ch1_Type Characteristic output 1
I16 no VP - -
2423.2 C3Plus.SignalFlowCharacteristic_Ch2_Curve_ID_
A
Which characteristic (ID) is used
I16 no VP - -
2423.1 C3Plus.SignalFlowCharacteristic_Ch2_Type Characteristic output 2
I16 no VP - -
2433.2 C3Plus.SignalFlowCharacteristic_Ch3_Curve_ID_
A
Which characteristic (ID) is used
I16 no VP - -
2433.1 C3Plus.SignalFlowCharacteristic_Ch3_Type Characteristic output 3
I16 no VP - -
1127.3 C3Plus.SPEED_speed Target speed in speed control
operating mode
7
C4_3 yes Immediat
ely
- -
680.8 C3Plus.StatusPosition_Actual_Y4 Status position actual value in the bus
format Y4
119 0x2022 Y4 yes - X X
2109.1 C3Plus.TrackingfilterHEDA_TRFSpeed Time constant tracking filter HEDA-
process position
I16 no VP - -
2107.1 C3Plus.TrackingfilterPhysicalSource_TRFSpeed Time constant tracking filter physical
source
U16 no VP - -
2110.7 C3Plus.TrackingfilterSG1_AccelFilter_us Filter time constant acceleration
setpoint generator
U16 no VP - -
2110.6 C3Plus.TrackingfilterSG1_FilterSpeed_us Filter time constant velocity setpoint
generator
U16 no VP - -
2110.1 C3Plus.TrackingfilterSG1_TRFSpeed Time constant tracking filter setpoint
encoder
0x2096 I16 no VP - -
210.9 C3Plus.ValidParameter_CamControlledSwitches Set cam switching mechanism
parameters to valid
338.9 0x2016.9 U16 no Immediat
ely
- -
210.5 C3Plus.ValidParameter_FeedForward
U16 no Immediat
ely
- -
210.2 C3Plus.ValidParameter_FiltersRSDP
U16 no Immediat
ely
- -
180.2 C3Plus.ValveOutput0_Gain Gain valve output 0
C4_3 no Immediat
ely
- -
180.4 C3Plus.ValveOutput0_Offset Offset valve output 0
I32 no Immediat
ely
- -
180.5 C3Plus.ValveOutput0_Value Value of valve output 0
C4_3 no Immediat
ely
- -
181.2 C3Plus.ValveOutput1_Gain Gain factor real
C4_3 no Immediat
ely
- -
181.4 C3Plus.ValveOutput1_Offset Offset valve output 1
I32 no Immediat
ely
- -
181.5 C3Plus.ValveOutput1_Value Value of valve output 1
C4_3 no Immediat
ely
- -
182.2 C3Plus.ValveOutput2_Gain Gain valve output 2
C4_3 no Immediat
ely
- -
182.4 C3Plus.ValveOutput2_Offset Offset valve output 2
I32 no Immediat
ely
- -
182.5 C3Plus.ValveOutput2_Value Value of valve output 2
C4_3 no Immediat
ely
- -
183.2 C3Plus.ValveOutput3_Gain Gain valve output 3
C4_3 no Immediat
ely
- -
183.4 C3Plus.ValveOutput3_Offset Offset valve output 3
I32 no Immediat
ely
- -
183.5 C3Plus.ValveOutput3_Value Value of valve output 3
C4_3 no Immediat
ely
- -
7.3 Detailed object list
A detailed object list can be found in the corresponding online help.
