Parker Compax3 Fluid T40

Parker EME
Positioning with IEC61131-3
192-121102 N04 June 2008 17
Compax3F is another member of the Parker Hannifin servo drive family.
Compax3F was especially designed to meet the requirements of electrohydraulic
systems for the control of position and force of hydraulic axes.
Compax3 Fluid – (Hydraulics controller)
Technical data
Motion control with motion profiles, suitable for position and force/pressure control
for up to 2 axes.
Command value generator
 Jerk-limited ramps.
 Travel data in increments, mm, inch.
 Specification of speed, acceleration, delay and jerk factor.
 Force/pressure data in N, bar, psi.
Monitoring functions
 Voltage range.
 Following error monitoring.
 Hard and Software limit switch
Technology functions of servo controllers
 IEC61131-3 programs in the servo controller (T30)
 Cam function in the servo controller (T40)
2. Positioning with IEC61131-3
Compax3F:
Electrohydraulic
servo drive
