Parker Compax3 Fluid T40

Compax3 Accessories C3F_T40
444 192-121102 N04 June 2008
11.5.4. Ref X11
SSK21/..: Cable for X11 with flying leads
5
Screen
2
7
3
6
9
1
Compax3
4
8
10
11
12
13
14
15
GY
PK
GN
RD
BU
WH
BN
YE
BK
VT
GYPK
RDBU
WHGN
BNGN
WHYE
YEBN
WHGY
GYBN
GY
PK
GN
RD
BU
WH
BN
YE
BK
VT
GYPK
RDBU
WHGN
BNGN
WHYE
YEBN
WHGY
GYBN
Pin 1
15
14
13
12
11
6
9
8
7
10
5
4
3
2
1
Lötseite
solder side
2 mm 6 mm
23 mm
You will find the length code in the
accessories order code (see page 429).
