Parker Compax3 Fluid T40

Parker EME
Motion control
192-121102 N04 June 2008 235
Absolute slave reference
Absolute reference can be established by coupling in with a coupling movement
(Mode 1 or 2)
S
l
a
v
e
C
a
m
o
u
t
p
u
t
360°
0°
Master Cam input
0°
360°
p
h
y
s
i
c
a
l
S
l
a
v
e
Start Source C3_MasterControl
& Start C3_CamTableSelect
Master Cam input: Master signal at the curve input
(C3Cam.StatusMaster_PositionCamUnits o3030.24)
Master signal: Master signal of the acquisition (C3Cam.StatusMaster_Position
o3030.1)
Slave: Signal at the curve output (C3Cam.StatusOutput_CurvePositionUnits
o3032.24)
The reference point and the curve zero point are always identical for absolute slave
reference with C3_CamIn.
5.10.6. Master signal source
In this chapter you can read about:
Setting the position of the selected master source (C3_SetMaster) ................................236
Recording the position of the selected master source (C3_MasterControl).....................237
Control of the cam generator (C3_CamTableSelect) .......................................................240
C3_MasterConfig..............................................................................................................243
Master signal phase shift (MC_Phasing)..........................................................................244
Note:
