Order code
192-121102 N04 June 2008 429
In this chapter you can read about:
Order code device: Compax3 Fluid..................................................................................429
Accessories order code....................................................................................................429
10.1 Order code device: Compax3 Fluid
C3
F 0 0 1 D2 F12
Hydraulics controller F
Table Style 0 0 1
Supply voltage 24VDC D2
Feedback Module F12
Interface:
Control via Inputs/Outputs I11
Control via Inputs/Outputs or COM interface I12
Profibus DP V0/V1/V2 (12Mbaud) I20
CANopen I21
DeviceNet I22
Ethernet Powerlink I30
Ethercat I31
Technology functions:
Positioning (available as I12T11 & I20T11) T11
Motion control programmable according to IEC61131-3 T30
Motion control programmable according to IEC61131-3 &
electronic cam extension
T40
Options:
no additional supplement M00
Expansion 12 digital I/Os & HEDA (Motionbus) M10
HEDA (Motionbus) M11
Expansion, 12 digital I/Os M12
10.2 Accessories order code
Order Code connection set for Compax3 Fluid
/
for C3F00xD2 ZBH 02/04
ZBH
0 2 / 0 4
Order code for feedback cables
/
X11, X13 with connector for Balluff BTL series with SSI- and Start/Stop
interface
GBK
4 0 / ... ...
X13 Feedback cable EnDat2.1
GBK
4 1 / ... ...
Encoder – Compax3
GBK 2 3 / ... ...
(1
