Parker Compax3 Fluid T40

Setting up Compax3 C3F_T40
118 192-121102 N04 June 2008
4.3.3.11 Analog Input
In this chapter you can read about:
Object 172.11: IN0 Offset ................................................................................................ 118
Object 172.4: IN0 Offset .................................................................................................. 118
Object 172.3: IN0 Filter.................................................................................................... 119
Object 173.11: IN1 Offset ................................................................................................ 119
Object 173.4: IN1 Offset .................................................................................................. 119
Object 173.3: IN1 Filter.................................................................................................... 119
Object 174.11: IN2 Offset ................................................................................................ 120
Object 174.4: IN2 Offset .................................................................................................. 120
Object 174.3: IN2 Filter.................................................................................................... 120
Object 175.11: IN3 Offset ................................................................................................ 120
Object 175.4: IN3 Offset .................................................................................................. 121
Object 175.3: IN3 Filter.................................................................................................... 121
Object 176.11: IN4 Offset ................................................................................................ 121
Object 176.4: IN4 Offset .................................................................................................. 121
Object 176.3: IN4 Filter.................................................................................................... 122
Object 177.11: IN5 Offset ................................................................................................ 122
Object 177.4: IN5 Offset .................................................................................................. 122
Object 177.3: IN5 Filter.................................................................................................... 122
Object 172.11: IN0 Offset
Object name
C3Plus.AnalogInput0_Offset_normed
Object No. 172.11 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
yes
CodeSys format:
REAL
Unit
mA
Minimum value
mA
Maximum value
mA
Remark:
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
C4_3
Object 172.4: IN0 Offset
Object name
C3.AnalogInput0_Offset
Object No. 172.4 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
no
CodeSys format:
INT
Unit
Increments
Minimum value
0 n/a
Maximum value
65535 n/a
Remark:
Offset in AD converter increments.
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I16
