Parker Compax3 Fluid T40

Setting up Compax3 C3F_T40
122 192-121102 N04 June 2008
Object 176.3: IN4 Filter
Object name
C3Plus.AnalogInput4_FilterCoefficient
Object No. 176.3 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
DINT
Unit
us
Minimum value
0 us
Maximum value
us
Remark:
Filter of time constant in us for the filtering of the input signal
0 => Filter off => output = input
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I16
Object 177.11: IN5 Offset
Object name
C3Plus.AnalogInput5_Offset_normed
Object No. 177.11 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
yes
CodeSys format:
REAL
Unit
V
Minimum value
V
Maximum value
V
Remark:
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
C4_3
Object 177.4: IN5 Offset
Object name
C3.AnalogInput5_Offset
Object No. 177.4 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
no
CodeSys format:
INT
Unit
n/a
Minimum value
n/a
Maximum value
n/a
Remark:
Offset in AD increments
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I16
Object 177.3: IN5 Filter
Object name
C3Plus.AnalogInput5_FilterCoefficient
Object No. 177.3 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
DINT
Unit
us
Minimum value
0 us
Maximum value
us
Remark:
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I16
