3.2.2. Plug and connector assignment
X13
X12
X11
X10
X3
X2
X1
LED1
X1
Analog Inputs
X2
Analog Outputs
X3
24 VDC power supply
X10
RS232/RS485
X11
2. Feedback Type
X12
Inputs/Outputs
X13
1. Feedback Type
Always switch devices off before wiring them!
