Error:
C3F_T40
428 192-121102 N04 June 2008
All errors lead to error status.
Two error reactions are possible which are assigned to the individual error:
Reaction 2: Downramp with error ramp and then switching the valve outputs with
high impedance (tristate) or, depending on the set
error reaction
(see page 80, see page 302) remaining in the controlled state.
The method of "downramping" depends on the operating mode
configured:
Position AND force control configured
Downramp with position control
Pure force congrol configured
Downramp with force control
Reaction
5
:
Immediate tristating of the valve outputs (without ramp).
With the aid of the "
SetErrorReaction (see page 302)" IEC module, additional
error reactions can be assigned to individual errors.
Most pending errors can be acknowledged with Quit!
The following errors must be acknowledged with "Power on":
0x7381, 0x7382, 0x7391, 0x7392, 0x73A0
The errors as well as the error history can be viewed in the C3 ServoManager
under optimization (at the top right of the optimization window).
9. Error:

Parker Compax3 Fluid T40 Specifications

General

Series	Compax3
Power Supply Voltage	24 VDC
Output Current	40A
Protection Class	IP20
Communication	CANopen, RS232
Operating Temperature	0°C to +45°C
Relative Humidity	5 to 95 %, non-condensing
Storage Temperature	-25 to +70 °C
