Motion control C3F_T40
276 192-121102 N04 June 2008
5.10.9.6 Example 6: Operation with curve segments and standstill area
Via a master cycle, a slave feed with following standstill is to take place from a
master position of 30° on; from a master position of 230° on, the slave is to
return. This sequence is to be repeated cyclically.
CamExample06.C3P (Compax3 project on the Compax3 CD:\Examples\Example6)
CamExample06.pro (CoDeSys project on the Compax3 CD:\Examples\Example6)
Input Function
I0 Energize axis, Homing
I1 Enable and start of the master position detection
I2 Start of the curve cycle
I3 Free
I4 Free
I5 Free
I6 Free
I7 Start of the virtual master
Corresponding files:
Control interface:
