Compax3 Accessories C3F_T40
440 192-121102 N04 June 2008
11.5 Interface Cables
In this chapter you can read about:
RS232 cable.....................................................................................................................441
RS485 cable to Pop..........................................................................................................442
I/O interface X12 / X22 .....................................................................................................443
Ref X11.............................................................................................................................444
Encoder coupling of 2 Compax3 axes..............................................................................445
Modem cable SSK31........................................................................................................446
Order code for interface cables and plugs
/
PC – Compax3 (RS232)
SSK
0 1 / ...
...
(1
PC - Compax3MP (USB)
SSK
3 3 / ... ...
on X11 (Ref/Analog) and X13 at C3F001D2 with flying leads
SSK
2 1 / ...
...
(1
on X12 / X22 (I/Os digital) with flying leads
SSK
2 2 / ...
...
(1
on X11 (Ref /Analog) for I/O terminal block
SSK
2 3 / ...
...
(1
on X12 / X22 (I/Os digital) for I/O terminal block
SSK
2 4 / ...
...
(1
PC POP (RS232)
SSK
2 5 / ...
...
(1
Compax3 POP (RS485) for several C3H on request
SSK
2 7 / ../
...
(6
Compax3 HEDA Compax3 HEDA or PC C3powerPLmC
Compax3 I30 Compax3 I30 or C3M-multi-axis communication
SSK
2 8 / ../
...
(5
Compax3 X11 Compax3 X11 (encoder coupling of 2 axes)
SSK
2 9 / ...
...
(1
Compax3 X10 Modem
SSK
3 1 / ...
Compax3H adapter cable SSK01 (length 15cm, delivered with the device)
SSK
3 2 / 2 0
Compax3H X10 RS232 connection control Programming interface (delivered with the device)
VBK
1 7 / 0 1
Bus terminal connector (for the 1st and last Compax3 in the HEDA Bus/or multi-axis system).
BUS
0 7 / 0 1
Profibus cable
(2
non prefabricated
SSL
0 1 / ...
...
(1
Profibus plug
BUS
0 8 / 0 1
CAN-Bus cable
(2
non prefabricated
SSL
0 2 / ...
...
(1
CANbus connector
BUS
1 0 / 0 1
(x
Note on the cable (see page 431)
