Parker EME
Order code
192-121102 N04 June 2008 431
(1
Length code 1
Length [m] 1,0 2,5 5,0 7,5 10,0 12,5 15,0 20,0 25,0 30,0 35,0 40,0 45,0 50,0
Order code 01 02 03 04 05 06 07 08 09 10 11 12 13 14
Example:
SSK01/09: length 25m
(2
Colours according to DESINA
(3
with motor plug
(4
with cable eye for motor terminal box
(5
Length code 2 for SSK28
Length [m] 0,17 0,25 0,5 1,0 3,0 5,0 10,0
Order code 23 20 21 01 22 03 05
(6
Order code: SSK27/nn/..
Length A (Pop - 1. Compax3) variable (the last two numbers according to the
length code for cable, for example SSK27/nn/01)
Length B (1. Compax3 - 2. Compax3 - ... - n. Compax3) fixed 50 cm (only if there is
more than 1 Compax3, i.e. nn greater than 01)
Number n (the last two digits)
Examples:
SSK27/05/.. for connecting from Pop to 5 Compax3.
SSK27/01/.. for connection from Pop to one Compax3
MOK55 and MOK54 can also be used for linear motors LXR406, LXR412 and
BLMA.
(x
Note on the cable (see page 431)
