4.1.1. C3HydraulicsManager
In this chapter you can read about:
Function description ...........................................................................................................44
Structure of the databases .................................................................................................44
4.1.1.1 Function description
With the aid of the C3Hydraulicsmanager, component databases for
 hydraulic valves (2/2, 3/3, 4/3 valves)
 actors (constant- and differential cylinders, hydromotors)
 Position feedback systems (with SSI-, Start/Stop, +/-10V-, 0..20mA-, RS422,
Sine/Cosine- or EnDat2.1 interface)
can be created and updated. A distinction is made between customer components
and Parker components. Databases with Parker components are already available
upon delivery, the customer has furthermore the possibility to create new
components from different suppliers in the customer database in order to make
possible their operation together with Compax3.
All component data can be called up and printed out. Existing components can be
used as templates for new components. A caracteristic with the specific flow rate
can be read in and memorized for each valve .
The detailed characterization of the components facilitates the commisisioning of
the hydraulic system, as a pre-parameterization of the control loop is effected
during the Compax3 configuration with the aid of these characteristic values.
An up-to-date Parker component database can be downloaded from the internet.
The customer component databases are not overwritten.
4.1.1.2 Structure of the databases
4 databases contain the data of the hydraulics components.
 Parker valves with characteristics (Valve.mdb)
 Parker actuators and path-measurement systems (CylinderDrive.mdb)
 Customer valves with characteristics (ValveC.mdb)
 Customer actuators and path-measurement systems (CylinderDriveC.mdb)
