5.13.5.3 Writing the PIO outputs 0-15 (PIO_Outputx...y)
FB name PIO_Output0_15
Is used for writing on the respective outputs
VAR_INPUT
O0 ... O15
BOOL Displays the status of the respective output.
Note: For the additional outputs, the following modules are available
PIO_Output16_31
PIO_Output32_47and
PIO_Output48_63.
Please execute this module at the end of the IEC program.
PIO_Output0_15
O5: BOOL
O6: BOOL
O7: BOOL
O1: BOOL
O2: BOOL
O3: BOOL
O0: BOOL
O4: BOOL
O13 : BOOL
O14 : BOOL
O15 : BOOL
O9: BOOL
O10 : BOOL
O11 : BOOL
O8: BOOL
O12 : BOOL
