6.6 DeviceNet
In this chapter you can read about:
DeviceNet Configuration...................................................................................................385
DeviceNet object classes .................................................................................................386
Data formats of the bus objects........................................................................................387
Please note:
A changed assignment (mapping) of the Input/Output Message is accepted
with Power off / Power on!
The length of the Input / Output Message is adapted to the real assignment
(mapping) (2...32).
Statement of Conformance
http://www.compax3.de/C3_DeviceNet_Statement_of
_Conformance.pdf (in the
Internet)
Address or Baud rate settings (see page 35)
Connector assignment (see page 35)
6.6.1. DeviceNet Configuration
In this chapter you can read about:
Error reaction to a bus failure ...........................................................................................385
Following are described the input windows of the configuration wizard.
Can be called up in the tree (Compax3 ServoManager, left window) under
"configure configuration".
6.6.1.1 Error reaction to a bus failure
Here you can adjust how Compax3 will respond to a fieldbus error:
Possible settings for the error reaction are:
 No response
 downramp / stop
 Downramp / switch to currentless (standard setting)
I22 Function
