5.10.4.1 Introduction to the CamDesigner (example)
Prerequisite:
Compax3 is configured
Compax3 ServoManager is installed (can be found on the Compax3 CD).
C3 CamDesigner is installed (can be found on the Compax3 CD).
Settings:
 Travel distance per motor revolution = 360°
 Reset distance = 360°
In the ”Configuration” wizard in the ”reference system” window
 Travel path per revolution of the physical source: Numerator = 360, Denominator
= 1
in the ”signal sources” wizard windows: ”Physical source”
 Signal source: Encoder A/B; 5V
Procedure:
Starting the CamDesigner: Nagivation tree of the Compax3 ServoManager under
”cam”: ”Modify cam with CamDesigner”
The transfer window from Compax3 ServoManager to CamDesigner will open:
