Parker Compax3 Fluid T40

Parker EME
Setting up Compax3
192-121102 N04 June 2008 53
Control range of the position controller.
The "control range" parameter
 --
 -100%...100%
 0...100% (P -> A)
 -100%...0 (A -> T)
 0...100% (B -> T)
 -100%...0 (P -> B)
defines the output range of the position controller for the selected valve.
If you enter "--", the valve is not influenced by the position controller.
Control range of the force/pressure control loop:
The "control range" parameter
 --
 -100%...100%
 0...100% (P -> A)
 -100%...0 (A -> T)
 0...100% (B -> T)
-100%...0 (P -> B)
defines the output range of the force/pressure controller for the selected valve.
If you enter "--", the valve is not influenced by the force/pressure controller.
4.1.8. Defining the reference system
The reference system for positioning is defined by:
 a unit,
 the travel distance per motor revolution,
 a machine zero point with true zero,
 positive and negative end limits.
4.1.8.1 Position transducer
For positioning operation of two axes with a Compax3F, we recommend an
absolute feedback system
Thus the homing run after switching on, which is only possible in coupled state for
2 axes and may lead to difficulties with definedly referencing the auxiliary axis is
not necessary.
Absolute feedback
system
