Parker Compax3 Fluid T40 User Manual

Parker EME
Motion control
192-121102 N04 June 2008 305
5.13.3.3 C3_IOAddition_2
FB name C3_IOAddition_2
Is used to create a process image of the optional digital inputs/outputs.
VAR_INPUT
I8 ... I11
BOOL Displays the status of the respective input.
O8 ... O11
BOOL Displays the status of the respective output.
Please note that the group of 4 may be assigned as inputs or as outputs (see
page 447). You may only use either inputs or o
utputs exclusively.
Notes: the module should always be brought up at the beginning of the processing
cycle.
OutputEnable : BOOL I8 : BOOL
C3_IOAddition_2
O8 : BOOL I9 : BOOL
I10 : BOOL
I11 : BOOL
Error : BOOL
O9 : BOOL
O10 : BOOL
O11 : BOOL

Parker Compax3 Fluid T40 Specifications

General

Series	Compax3
Power Supply Voltage	24 VDC
Output Current	40A
Protection Class	IP20
Communication	CANopen, RS232
Operating Temperature	0°C to +45°C
Relative Humidity	5 to 95 %, non-condensing
Storage Temperature	-25 to +70 °C
