Parker Compax3 Fluid T40

Setting up Compax3 C3F_T40
120 192-121102 N04 June 2008
Object 174.11: IN2 Offset
Object name
C3Plus.AnalogInput2_Offset_normed
Object No. 174.11 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
yes
CodeSys format:
REAL
Unit
mA
Minimum value
mA
Maximum value
mA
Remark:
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
C4_3
Object 174.4: IN2 Offset
Object name
C3.AnalogInput2_Offset
Object No. 174.4 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
no
CodeSys format:
INT
Unit
Increments
Minimum value
n/a
Maximum value
n/a
Remark:
Offset in AD increments. Range 0..65535.
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I16
Object 174.3: IN2 Filter
Object name
C3Plus.AnalogInput2_FilterCoefficient
Object No. 174.3 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
DINT
Unit
us
Minimum value
us
Maximum value
us
Remark:
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
Object 175.11: IN3 Offset
Object name
C3Plus.AnalogInput3_Offset_normed
Object No. 175.11 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
yes
CodeSys format:
REAL
Unit
mA
Minimum value
mA
Maximum value
mA
Remark:
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
C4_3
