Motion control C3F_T40
234 192-121102 N04 June 2008
Relative slave reference example 2
Example 1: MC_CamIn is started after the curve start and the master position
acquisition:
S
l
a
v
e
C
a
m
o
u
t
p
u
t
360°
0°
Master Cam input
p
h
y
s
i
c
a
l
S
l
a
v
e
MC_CamIn.Execute
1
pre Cam Cam
Start Source
C3_MasterControl,
Start
C3_CamTableSelect
1: Alignment of the current slave setpoint position from the curve with the current
setpoint position from the history of the Execute of the MC_CamIn
Master Cam input: Master signal at the curve input
(C3Cam.StatusMaster_PositionCamUnits o3030.24)
Master signal: Master signal of the acquisition (C3Cam.StatusMaster_Position
o3030.1)
Slave: Signal at the curve output (C3Cam.StatusOutput_CurvePositionUnits
o3032.24)
If a closed curve is combined with absolute master reference, an entry with
MC_CamIn at a master position > 0 will lead to a backwards movement of the axis
with reference to the start point.
Note:
