Relative slave reference example 1
Example 1: MC_CamIn is started before or upon the curve start and the
master position acquisition:
S
l
a
v
e
C
a
m
o
u
t
p
u
t
360°
0°
Master Cam input
Start Source
C3_MasterControl,
MC_CamIn &
Start
C3_CamTableSelect
180°
540°
p
h
y
s
i
c
a
l
S
l
a
v
e
Master Cam input: Master signal at the curve input
(C3Cam.StatusMaster_PositionCamUnits o3030.24)
Master signal: Master signal of the acquisition (C3Cam.StatusMaster_Position
o3030.1)
Slave: Signal at the curve output (C3Cam.StatusOutput_CurvePositionUnits
o3032.24)
