Parker EME
Motion control
192-121102 N04 June 2008 223
• 47 harmonic combination
For all other interpolations, the 5th order polynomial is used in the basic version. In
the "Advanced Version", all methods of interpolation (also in combination) are
possible in general. A detailed description of the methods not mentioned here, can
be found in the CamDesinger help.
The dwell-to-dwell motion law can also be specified in the header data mask of the
CamDesigner.
11 if the option "always calculate motion diagrams" is activated, the CamDesigner
will calculate the interpolated motion sequence and the acceleration sequence
after each change.
This option can also be de-/activated in the header data mask of the
CamDesigner.
12 Modular grid for graphic cam input.
These values determine to which master/slave grid the curve elements placed
with the aid of the mouse are brought ("catched"). The grid of the master (x)-
axis must be smaller than the configured clock distance.
These values can also be de-/activated in the input mask of the CamDesigner
for curve points.
13 Here are displayed status resp. error messages and notes.
14 Starting the CamDesigner.
This must be installed from the Compax3 CD before.
After the return from the CamDesigner it is necessary to perform a curve data
download in order to load the changes into Compax3 (even if the curves
themselves were not modified).
15 Cancel. Closing gehe window, the changes are discarded.
Motion laws:
Detailed information on the topic of "motion laws" can be found in the online help of
the device.
