Parker Compax3 Fluid T40

Motion control C3F_T40
290 192-121102 N04 June 2008
Example 2: Working cycles for:
 no fast cams,
 8 serial cams and
 reduced cycle time (object O3701.6 = 3)
1 2 3 4 5 6 7 8 1 2 3
500µs
1,5ms
Example 3: Working cycles for:
 no fast cams,
 8 serial cams and
 reduced cycle time (object O3701.6 = 4)
1 2 3 5 6
500µs
4 7 8 1 2 3 5 64 7
1ms
