Parker EME
Communication
192-121102 N04 June 2008 339
DIP Switch settings NetCom 113 for two-wire operation:
1ON 2ON 3off 4off (Mode: RS485 by ART (2 wire without Echo)
Communication settings C3S/C3M:
Object Function Value
810.1 Protocol 16 (two wire)
810.2 Baud rate 115200
810.3 NodeAddress 1..254
810.4 Multicast Address
Connection plan NetCom113<-> C3S:
Connection plan NetCom113<-> C3M X31:
