Parker Compax3 Fluid T40

Communication
C3F_T40
404 192-121102 N04 June 2008
Master and Slave 1 to 3 (from left to right).
Task:
Master Transmit
 Master sends on:
 Slot 0...2: Mapping table 1
 Slot 3..0.7: Mapping table 2
 Slot 8..0.12: Mapping table 4
 Slot 13..0.17: Mapping table 5
Slave Receive
 Slave 1 reads on:
 Slot 2: Mapping table 1
 Slot 3: Mapping table 2 and
 Slot 8: Mapping table 4
 Slave 2 reads on:
 Slot 6: Mapping table 2
 Slot 9: Mapping table 4 and
 Slot 13: Mapping table 5.
 Slave 3 reads on
 Slot 1: Mapping table 1 and
 Slot 9: Mapping table 4.
Slave Transmit
 Slave 1 sends on:
 Slot 1: Mapping table 1
 Slot 5: Mapping table 6
 Slave 2 sends on:
 Slot 8: Mapping table 7
 Slave 3 sends on:
 Slot 17: Mapping table 8
Master Receive
 Master receives on:
 Slot 1: Mapping table 1
 Slot 5: Mapping table 6
 Slot 8: Mapping table 7
 Slot 17: Mapping table 8
