Specifications
192-121102 N04 June 2008 459
Profibus ratings
Profile
 PROFIdrive Profile drive system V3
DP Versions
 DPV0/DPV1
Baud rate
 up to 12MHz
Profibus ID
 C320
Device master file
 PAR_C320.GSD
(can be found on the Compax3 - CD)
Communication
Simatic <-> Compax3
 Simatic S7-300/400 - modules for
Compax3 I20 and a corresponding help
file can be found on the Compax3 CD in
the folder: ..\Profibus\S7-moduls\
CANopen ratings
Baud rate [kBit/s]
 20, 50, 100, 125, 250, 500, 800, 1000
EDS file
 C3.EDS
Service data object
 SDO1
Process data objects
 PDO1, ... PDO4
DeviceNet characteristic data
DeviceNet
 Predefined Master/Slave Connection Set
 Standard 2.0 Group-2-Slave
 Fieldbus I/O Data or Process Data
(Polled, COS/Cyclic I/O and Bit Strobe)
Implemented object classes
 Identify, Message Router, DeviceNet,
Assembly, Connection, Acknowledge
Handler
Baud rate [kBit/s]
 125, 250, 500
permissible cable length
 up to 500m on 125Bit/s,
 up to 200m on 250Bit/s,
 up to 100m on 500Bit/s,
Max. number of nodes
 63 Slave
Insulation
 Isolated Device Physical Layer
EDS file
 C3_DeviceNet.EDS
Conformance (file in the Internet)
 Statement of Conformance
http://www.compax3.de/C3_DeviceNet_S
tatement_of_
Conformance.pdf
Further information:
 Application example
(C3I22_DeviceNet.ZIP) on the Compax3
CD in the "\Examples" directory
I20 Function
I21 Function
I22 Function
