2.8 PAPER FEED
2.8.1 OVERVIEW
This model has three built-in paper feed trays: tandem feed tray [A] (500 + 500
sheets), universal tray [B] (550 sheets) and built-in LCT [C] (1500 sheets).
Paper can also be fed using the by-pass feed table [D] which has an independent
feed mechanism. The by-pass feed table can hold 50 sheets of paper.
All feed stations use an FRR feed system.
A229D615.WMF
[A]
[B]
[C]
[D]
