Ricoh A229 - Auto off Mode; Off Mode (Sleep Mode)

ENERGY SAVER MODES
2-129
Detailed
Descriptions
SM A229
2.11.4 OFF MODE
Off mode has two separate modes.
•
Auto Off Mode (Sleep mode)
•
Weekly Timer Off Mode
Off Mode (Sleep Mode)
Entering off mode
The machine enters off mode when one of the following is done.
•
The auto off timer runs out after the end of a job
•
The operation switch is pressed to turn the power off
What happens in off mode
When the machine enters auto off mode, the operation switch turns off
automatically. The fusing lamp and all dc supplies except +5VE (+5V for energy
saver mode) turns off. At this time, only the main power LED is lit.
Operation
Switch
Energy
Saver LED
Fusing Temp.
System +5V Main Power
LED
Off Off
Room Temp.
(Fusing lamp off)
Off On
NOTE:
Only +5VE is supplied to the SBICU.
LED (+5V) is supplied to the operation panel from the SBICU.
Returning to stand-by mode
The machine returns to stand-by mode when the operation switch is pressed.
Printing incoming data
If the machine receives print data from a PC, the fusing temperature rises to print
the data. However, the operation panel stays off. After completing the print job, the
machine returns to off mode (sleep mode).
