MailBox &
Bridge Unit
G909/G912
DIP SWITCHES/VRIABLE RESISTORS/LEDS
SM 10-27 A229
5. SERVICE TABLES
5.1 DIP SWITCHES/VRIABLE RESISTORS/LEDS
5.1.1 DIP SWITCHES
0 = OFF 1 = ON
Switch No.
Item
1234
Function
Default 0000
Motor Test 1000
Solenoid Test 0100
When detecting paper between the
1st and 3rd trays, LED2 will light.
When detecting paper between the
4th and 6th trays, LED3 will light.
Tray Exit Sensor Check 1100
When detecting paper between the
7th and 9th trays, LED4 will light.
Paper Sensor Check
(1st to 3rd trays)
0010When the 1st tray paper sensor is
activated, LED2 will light.
When the 2nd tray paper sensor is
activated, LED3 will light.
When the 3rd tray paper sensor is
activated, LED4 will light.
Paper Sensor Check
(4th to 6th trays)
1010When the 4th tray paper sensor is
activated, LED2 will light.
When the 5th tray paper sensor is
activated, LED3 will light.
When the 6th tray paper sensor is
activated, LED4 will light.
Paper Sensor Check
(7th to 9th trays)
0110
When the 7th tray paper sensor is
activated, LED2 will light.
When the 8th tray paper sensor is
activated, LED3 will light.
When the 9th tray paper sensor is
activated, LED4 will light.
Proof Tray Sensors Check1110
When the proof paper overflow
sensor is activated, LED2 will light.
When the proof paper sensor is
activated, LED3 will light.
Paper Overflow Sensor
Check (1st to 3rd trays)
0001When the 1st paper overflow
sensor is activated, LED2 will light.
When the 2nd paper overflow
sensor is activated, LED3 will light.
When the 3rd paper overflow
sensor is activated, LED4 will light.
Paper Overflow Sensor
Check (4th to 6th trays)
1001When the 4th paper overflow
sensor is activated, LED2 will light.
To Next Page
