PAPER SIZE CHANGE
A229 3-16 SM
3.3.3 TANDEM FEED TRAY PAPER SIZE CHANGE (TRAY 1)
NOTE:
At the factory, this tray is set up for A4 or LT sideways. Only B5, A4, or LT
sideways paper can be used for tandem feed. If the user requests other
paper sizes than these, this tray will be used as a fixed tray.
- To use as a tandem feed tray for A4, LT, or B5 sideways paper -
1. Draw out the tandem feed tray [A].
2. Remove the rear and front side fences [B] (one screw and one pushlock each)
on the right tandem tray.
3. Re-position the end fences [C] on both rear and front side fences (1 screw
each) to match the required paper size.
A229I508.WMF
A229I509.WMF
[A]
[B]
[B]
[B]
[C]
To Next Page
