DRIVE LAYOUT
1-12
A229 SM
1.6 DRIVE LAYOUT
1.6.1 COPIER ENGINE
1. Drum Motor
2. Scanner Motor
3. Fusing/Duplex Motor
4. Toner Recycling Clutch
5. Paper Feed Motor
6. Toner Collection Motor
7. Registration Motor
8. Relay Clutch
9. By-pass Feed Motor
10. By-pass Feed Clutch
11. Development Motor

Cleaning Unit

Scanner Unit

Transfer Belt Unit

Fusing Unit

Duplex Unit

Paper Feed Units

Toner Hopper

Development Unit

Drum
A229V505.WMF
1
3

5
6
7
8
9
10
11
2








4

