4.4.5 IMAGE QUALITY SETTING BY UP MODE
The ‘Original Mode Quality Level in Copy Features’ UP mode is related to the ‘MTF
Filter Settings’ SP mode.
If a setting from the above three columns [A] is selected, the MTF coefficient (SP4-
903-011 to 019, 041 to 047) and MTF strength (SP4-903-20 to 23, 050 to `053) are
fixed. Any changes to the SP mode settings are not reflected in the copy. To use
the settings specified by SP mode, the user must select “SP mode Changed” [B].
The detailed relationship between the different original modes, the UP modes, and
the SP modes are as follows.
Text mode
Magnification Ratio: 32
−
64%
MTF Filter Strength Strong Weak
UP mode Sharp
Normal
Soft
Coefficient Level –
Main Scan
SP4-903-011 6 4 651 2 1
Coefficient Level
– Sub Scan
SP4-903-041 8 687342
Strength Level –
Main Scan
SP4-903-020 4 322210
Strength Level
– Sub Scan
SP4-903-050 4 322210
Soft
Photo Mode
Screened Printed
Soft
Soft
Sharp
Text Mode
Continuous Tone
Sharp
Sharp


Normal





Normal





Normal





Normal





Normal
Text
Text/Photo
Pale
Generation
SP Mode Changed
SP Mode Changed
SP Mode Changed
SP Mode Changed
SP Mode Changed
