MailBox &

Bridge Unit

G909/G912

COMPONENT LAYOUT

SM 10-3 A229

1.2.2 DRIVE LAYOUT

1. Proof Tray Exit Roller

2. Proof Tray Transport Motor

3. Bridge Exit Roller

4. Transport Motor

5. Entrance Roller

6. Vertical Transport Motor

7. Tray Feed-out Roller

G909V501.WMF

G909V502.WMF

G909V503.WMF
