SERVICE PROGRAM MODE
4-57
SM A229
Service
Tables
4.2.5 OUTPUT CHECK
WARNING:
Motors keep turning in this mode regardless of upper or lower limit sensor
signals. To prevent mechanical or electrical damage, do not keep an
electrical component on for a long time.
Main Machine Output Check (SP5-804)
1. Access SP mode 5-804.
2. Select the SP number that corresponds to the component you wish to check.
3. Press ON to check that component.
4. Press “OFF” to end the test.
5. If you wish to check another component, press the “Next” or “Prev.” Key.
No. Description No. Description
1 1st Paper Feed Clutch 38 Relay Clutch (LCT)
2 2nd Paper Feed Clutch 39 Registration Motor
3 3rd Paper Feed Clutch 40 Guide Plate Solenoid
4 Not Used 41 Inverter Gate Solenoid
5 By-pass Feed Clutch 42 Not used
6 Paper Feed Clutch (LCT) 43 Duplex Transport Clutch
7, 8 Not used 44 Duplex Feed Clutch
9 1st Pick-up Solenoid 45 Duplex Inverter Gate Solenoid
10 2nd Pick-up Solenoid 46 Reverse Roller Solenoid
11 3rd Pick-up Solenoid 47~ 52 Not used
12 Not Used 53 Development Motor
13 By-pass Pick-up Solenoid 54 Toner Recycling Motor
14 Pick-up Solenoid (LCT) 55 Not used
15, 16 Not used 56 Toner Supply Motor
17 1st Separation Roller Solenoid 57 Transfer Belt Solenoid
18 2nd Separation Roller Solenoid 58 ~ 61 Not used
62 Quenching Lamp
19 3rd Separation Roller Solenoid 63 Charge Corona
20 ~ 23 Not used 64 Grid Plate
24 Rear Fence Motor 65, 66 Not used
25 LCT Motor (LCT) 67 Development Bias
26 Paper Feed Motor 68 Not used
27 By-pass Feed Motor 69 Transfer Belt Bias
28 Drum Motor 70 ID Sensor
29 ~ 30 Not used 71 ~ 73 Not used
31 Fusing/Duplex Motor 74 Optics Cooling Fan
32 1st Vertical Relay Clutch 75 Duplex Cooling Fan
33 2nd Vertical Relay Clutch 76 Exhaust Fan (Low speed)
34 3rd Vertical Relay Clutch 77 Exhaust Fan (High speed)
35 Not used 78 Fusing Fan
36 Relay Clutch 79 Not used
Rev. 12/15/98
