SM A229

Overall

Information

1.2 MACHINE CONFIGURATION

Item Machine Code No.

Mainframe A229 3

Output Tray A814 - 01 2

Finisher A697 1

Large Capacity Tray A698 4

Punch Unit (Option for Finisher)

A812-17 (3 holes)

A812-27 (2 holes)

A229V501.WMF
