Ricoh A229 - Service Program Mode Tables

SERVICE PROGRAM MODE
4-10
A229 SM
4.2.2 SERVICE PROGRAM MODE TABLES
NOTE:
1) In the Function column, comments are in italics.
2) In the Settings column, the default value is in bold letters.
3) An asterisk ( * ) in the right hand side of the mode number column
means that this mode is stored in the NVRAM. If you do a RAM reset, all
these SP modes will be reset to their factory settings.
Mode No.
(Class 1 , 2
&
3)
Function Settings
1-001 Leading Edge Registration
*
Adjusts the printing leading edge
registration using the trimming area pattern
(SP2-902-3, No.10).
+9 ~ -9
0.1
mm/step
+ 3.0 mm
Use the “
•
” key to toggle from + to - and
the Clear/Stop key to toggle from - to +
before entering the value. The specification
is 0
±
2.0 mm..
The specification is 3
±
2 mm. See
"Replacement and Adjustment - Copy
Image Adjustments" for details.
1-002 Side-to-Side Registration
1 Tray - 1 * Adjusts the printing side-to-side
registration from the 1st paper feed station
using the trimming area pattern (SP2-902-
3, No.10).
+9 ~ -9
0.1
mm/step
+ 0.0 mm
Use the “
•
” key to toggle from + to - and
the Clear/Stop key to toggle from - to +
before entering the value. The specification
is 0
±
2.0 mm.
See "Replacement and Adjustment - Copy
Image Adjustments" for details on
SP1-002.
2 Tray - 2 *
Adjusts the printing side-to-side registration
from the 2nd paper feed station using the
trimming area pattern (SP2-902-3, No.10).
+9 ~ -9
0.1
mm/step
+ 0.0 mm
Use the “
•
” key to toggle from + to - and
the Clear/Stop key to toggle from - to +
before entering the value.The specification
is 0
±
2.0 mm.
3 Tray - 3 *
Adjusts the printing side-to-side registration
from the 3rd paper feed station using the
trimming area pattern (SP2-902-3, No.10).
+9 ~ -9
0.1
mm/step
+ 0.0 mm
Use the “
•
” key to toggle from + to - and the
Clear/Stop key to toggle from - to + before
entering the value.
The specification is 0
±
2.0 mm.
4 Tray - 4 *
Japanese version only.
5 Duplex Tray *
Adjusts the printing side-to-side registration
from the duplex tray using the trimming area
pattern (SP2-902-3, No.10).
+9 ~ -9
0.1
mm/step
+ 0.0 mm
Use the “
•
” key to toggle from + to - and the
Clear/Stop key to toggle from - to + before
entering the value.
The specification is 0
±
2.0 mm.
Rev. 12/15/98
