SERVICE PROGRAM MODE
4-58
A229 SM
No. Description No. Description
37 Not used 80 Tray Junction Gate Solenoid
(Finisher)
81
Stapler Junction Gate Solenoid
(Finisher)
90 Laser Diode
82
Positioning Roller Solenoid
(Finisher)
91 Not used
83 Not used 92 Tray Lift Motor (Finisher)
84 Mechanical Counter 93 Jogger Motor (Finisher)
85 Upper Transport Motor (Finisher) 94 Stapler Motor (Finisher)
86 Lower Transport Motor (Finisher) 95 Stack Feed-out Belt Motor
(Finisher)
87 Shift Tray Exit Motor (Finisher) 96 Shift Motor (Finisher)
88 Staple Hammer Motor (Finisher) 97 Stapler Rotation Motor (Finisher)
89 Punch Motor (Punch Unit) 98 ~ 99 Not used
ADF Output Check (SP6-008)
No. Description
1 Feed-in Motor (Forward)
2 Feed-in Motor (Reverse)
3 Transport Motor (Forward)
4 Transport Motor (Reverse)
5 Feed-out Motor
6 Exit Gate Solenoid
7 Inverter Gate Solenoid
8 DF Indicators
9 Pick-up Motor (Forward)
10 Bottom Plate Motor
4.2.6 SYSTEM PARAMETER AND DATA LISTS (SMC LISTS)
1. Access the SP mode corresponding to the list that you wish to print.
1) SP5-990-1 : All system parameter list
2) SP5-990-2 : SP mode data list
3) SP5-990-3 : UP mode data list
4) SP5-990-4 : Machine status history data list
5) SP5-990-5 : Copy mode list (UP mode No.10)
6) SP5-990-6 : SP mode data list with a large font size
2. Select the paper size and press "Start" on the display.
3. After printing the list, exit SP mode.
Rev. 12/15/98
