DIP SWITCHES
SM 7-21 A229
Finisher
A697
3. SERVICE TABLES
3.1 DIP SWITCHES
DPS100 DPS101
12341234
Description
00000000Default
11011000Stack feed-out motor on
11100100Free run: sort/stack mode
1 1 1 0 0 0 1 0 Free run: one staple (front side)
11100001Free run: two staples
NOTE: Do not use any other settings.
3.2 TEST POINTS
No. Label Monitored Signal
TP101 (GND) Ground
3.3 LED
No. Function
LED100 Monitors the stack feed-out motor speed.
3.4 VARIABLE RESISTORS
No. Function
VR100 Adjust the stack feed-out motor speed.
3.5 FUSES
No. Function
FU100 Protects 24 V.
