Ricoh A229 - Left; Upper Left Cover; Lower Left Cover

EXTERIOR
SM 5-3 A229
Replacement
and
Adjustmen
t
5.1.3 LEFT
Upper Left Cover
1. Remove the upper left cover [A] (2 screws).
Lower Left Cover
1. Remover the lower left cover [B] (2 screws).
NOTE:
When re-installing the covers, put the hooks in the holes in the frame.
A229R640.WMF
[A]
[B]
