DIP SWITCHES/VRIABLE RESISTORS/LEDS
A229 10-28 SM
Switch No.
Item
1234
Function
Paper Overflow Sensor
Check (4th to 6th trays)
1001
When the 5th paper overflow
sensor is activated, LED3 will light.
When the 6th paper overflow
sensor is activated, LED4 will light.
Paper Overflow Sensor
Check (7th to 9th trays)
0101When the 7th paper overflow
sensor is activated, LED2 will light.
When the 8th paper overflow
sensor is activated, LED3 will light.
When the 9th paper overflow
sensor is activated, LED4 will light.
Entrance, Bridge Relay,
and Bridge Exit Sensor
Check
1101When the entrance sensor is
activated, LED4 will light.
When the bridge relay sensor is
activated, LED3 will light.
When the bridge exit sensor is
activated, LED2 will light.
Proof Exit and Relay
Sensor Check
0011When the proof exit sensor is
activated, LED4 will light.
When the relay sensor is activated,
LED3 will light.
Free Run 1111
5.1.2 VARIABLE RESISTORS
Number Function
VR1 Adjusts the tray exit sensor sensitivity between trays 1 and 3
VR2 Adjusts the tray exit sensor sensitivity between trays 4 and 6
VR3 Adjusts the tray exit sensor sensitivity between trays 7 and 9
5.1.3 LEDS
Number Monitored Signal
LED1 Monitors the software operation.
Blinking: Normal operation
Others: Abnormal operation
LED2
LED3
LED4
The LED lights when the appropriate sensor is activated. (Refer to the
DIP switch table for more details.)
