Ricoh A229 - ADF Input Check (SP5-007)

SERVICE PROGRAM MODE
4-56
A229 SM
ADF Input Check (SP6-007)
ReadingClass 3 no. Bit no. Description
01
1 0 Original Set Sensor No Original Original
detected
1 Original Width Sensor 1 No Original
Original
detected
2 Original Width Sensor 2 No Original Original
detected
3 Original Width Sensor 3 No Original Original
detected
4 Entrance Sensor No Original
Original
detected
5 Registration Sensor No original Original
detected
6 Exit Sensor No original Original
detected
7 Inverter Sensor No original
Original
detected
2 0 DF Position Sensor Down Up
1 APS Start Sensor Start Off
2 Feed Cover Sensor Close Open
3 Exit Cover Sensor Close Open
4 Bottom Plate HP Sensor At home
position
Not home
position
5
Bottom Plate Position
Sensor
Detected Not detected
6 Pick-up Roller HP Sensor At home
position
Not home
position
7 Not used
Rev. 12/15/98
