BRIDGE UNIT FOR MAILBOX (G912)
SM 10-15 A229
3.2 BRIDGE UNIT FOR MAILBOX (G912)
3.2.1 ACCESSORY CHECK
Check the accessories in the box against the following list.
No. Description Q’ty
1. Guide Plate Bracket 1
2 Cable 1
3 Cover Switch 1
4 Grounding Bracket 1
5 Finisher Shielding Plate 1
6Screw - M4 x 8 9
7Screw - M4 x 4 4
8Screw - M3 x 6 2
G912I500.WMF
1
2
3
4
5
6
7
8
