PM TABLE
4-77
SM A229
SERVICE
TABLES
EM 150K 300K 450K NOTE
Toner Bottle Holder C C C Dry cloth or vacuum cleaner
Toner Hopper Entrance C C C Dry cloth
PAPER FEED (Main frame and by-pass tray)
Registration Rollers CCCWater or alcohol
Relay Roller CCCWater or alcohol
Paper Dust Remover CCCDry cloth
Paper Feed Roller (by-
pass tray)
RRRReplace the pick-up, feed, and
separation rollers as a set.
Check the counter value for the
by-pass tray (SP7-204-6). If the
value has reached 150k, replace
the rollers. After replacing the
rollers, reset the counter (SP7-
816-6).
Registration Sensor CCCBlower brush
Relay Sensor CCCBlower brush
PAPER FEED (For each paper feed station)
Paper Feed Guide Plate CCCWater or alcohol
Paper Feed Rollers RRRReplace pick-up, feed and
separation roller as a set.
Check the counter value for each
paper tray station (SP7-204). If
the value has reached 150k,
replace the rollers. After replacing
the rollers, reset the counter
(SP7-816).
Vertical Transport Roller CCCWater or alcohol
Paper Feed Sensor CCCBlower brush
TRANSFER BELT UNIT
Transfer Belt CRCDry cloth
Cleaning Roller Cleaning
Blade
RRR
Transfer Entrance Guide
Plate
CCCDry cloth
Belt Drive/Guide/
Bias Roller/Cleaning
Roller
C Alcohol
Transfer Exit Guide Plate CCCDry cloth
FUSING/PAPER EXIT
Hot Roller R R R
Hot Roller Bearings IIIIReplace if necessary.
Pressure Roller C R C Use a suitable solvent.
Pressure Roller Bearings I R I
Fusing Thermistor IIIIReplace if necessary.
Hot Roller Strippers CCRCWater or alcohol
Oil Supply Roller
Bushings
IIIIReplace if necessary.
Pressure Roller Cleaning
Roller and Bushings
R R R Replace as a set.
