PM TABLE
4-78
A229 SM
EM 150K 300K 450K NOTE
Oil Supply Roller R R R
Oil Supply Cleaning
Roller
RRR
Replace these parts as a set.
Cleaning Roller Brush
(EU only)
CRCDry cloth
Cleaning Roller Support
Plate
IIIIReplace if out of shape
Fusing Entrance and Exit
Guide Plates
C C C Clean with water or alcohol
Transport/Exit Rollers C Water
Exit Anti-static Brush I I I
DUPLEX
Entrance Sensor C C C Blower brush
Reverse Roller C C C
Separation Rollers C C C
Duplex Roller C C C
Feed Rollers C C C
Water or alcohol
Entrance Anti-static
Brush
III
Reverse Junction Gate C C C Dry cloth
OTHERS
Ozone Filter R
Used Toner Tank IIIIReplace if necessary (about
1,500k copies).
EM 80K 160K 240K NOTE
ADF (the PM interval is for the number of originals that have been fed)
Transport Belt CRRRBelt cleaner
Feed Belt CRRRBelt cleaner
Separation Roller CRRRDry or damp cloth
Pick-up Roller CRRRDry or damp cloth
Sensors CCCCBelt brush
Drive Gears L L L Grease G501
EM 150K 300K 450K NOTE
LCT
Paper Feed Roller R R R
Pick-up Roller R R R
Separation Roller R R R
Check the counter value for
the LCT (SP7-204-5). If the
value has reached 150k,
replace the rollers. After
replacing the rollers, reset the
counter (SP7-816-5).
Bottom Plate Pad C C C Dry or damp cloth
Paper Feed Clutch Replace at 1,500k
Relay Clutch Replace at 1,500k
Pick-up Solenoid Replace at 1,500k
To Next Page
