TRAY UNIT
A229 10-26 SM
8. Turn back the VR slowly until the LED just turns on.
9. Measure the voltage between TP3 on the main control board and the frame of
the mailbox and confirm the voltage is greater than 3.5 Vdc. If it is not, adjust
the voltage using the VR (the relationship between tray, TP, and VR are shown
in the table below).
10. Remove the special paper from the tray, then measure the voltage on the main
control board in the same way as step 9. The voltage should be less than 1.2
Vdc.
11. After adjusting, change the DIP switch setting to the default (all switches off)
and reassemble the machine.
Adjusted Sensor VR No. LED No. TP No.
Trays 1 to 3 VR1 LED 2 TP3
Trays 4 to 6 VR2 LED 3 TP4
Trays 7 to 9 VR3 LED 4 TP13
NOTE:
The DIP switches to change are the same regardless of the adjusted
sensor.
To Next Page
