SERVICE PROGRAM MODE
4-54
A229 SM
Reading
Class 3 no. Bit no. Description
01
8
(I/O Board
Dip Switch
101)
7 Dip Switch – 8 On Off
6 Dip Switch – 7 On Off
5 Dip Switch – 6 On Off
4 Dip Switch – 5 On Off
3 Dip Switch – 4 On Off
2 Dip Switch – 3 On Off
1 Dip Switch – 2 On Off
0 Dip Switch – 1 On Off
7 Drum Motor Lock Overload Normal
6 By-pass Feed Motor Lock Overload Normal
9
(Motor Lock
/Transport)
5 Development Motor Lock Overload Normal
4 Fusing Motor Lock Overload Normal
3Not Used
2 Fusing Exit Sensor Paper detected No paper
1 Exit Sensor Paper detected No paper
0 Tray Paper Limit Sensor Not full Full
10 7 Duplex Entrance Sensor Detected Not detected
(Duplex) 6 Duplex Transport 3 Sensor Detected Not detected
5 Duplex Transport 2 Sensor Detected Not detected
4 Duplex Transport 1 Sensor Detected Not detected
3 Duplex Jogger HP Sensor Not detected Detected
2 Duplex Connection Connected
Not
Connected
1 Toner Pump Connection Connected Not
Connected
0 Guide Plate Position
Sensor
In position Out of
position
11 7 LCT Motor Lock Overload
Normal
(LCT1) 6 LCT Tray Down Switch On Off
5 LCT Connection Connected Not
connected
4 LCT Cover Open Switch Closed Open
3 LCT Paper End Sensor Paper end Not paper
end
2 LCT Down Sensor Not detected Detect
1 LCT Lift Sensor Layout Not lifted
0 LCT Paper Height 1
Sensor
Not detected Detected
12 7 Fusing Zero Cross Detected Not detected
(LCT2) 6 Not Used
5 Front Door Safety Switch Closed Open
4Not Used
