Specifically the batch objects are:
● Batch types:
– Data types
– Units of measure
– Phase types
– Operation types
– Process tag types
– Equipment properties
● Batch instances:
– Process cell (folder) → currently selected object
– Units (folder)
– Equipment properties
– Equipment modules (EMOD) (folder)
– Neutral folder
– Equipment phases (EPH)
– Parameters of equipment phases
– Equipment operations (EOP)
– Parameters of equipment operations
– Process tags
– Process tag parameters
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the navigation tree.
Description Any object description by the user.
Process cell component group‐
ing
If you have configured one or more enumerations as an equipment
property, you can set one of them as a grouping criterion from the
drop-down list.
Migrated to version Specification of the SIMATIC BATCH version for which the data
have been migrated (e.g., 08.01.00.00_00.00.00.00).
Context help references
